Large Electric Forklift

A Gentle Giant for Your Toughest Jobs

Toyota’s Large Electric Forklift gets the job done, quietly and reliably. With 12,000 pounds of lifting power, and zero-emissions, this gentle giant can tackle your toughest warehousing challenges with a whisper quiet ride.

Load Capacity 8,000 – 12,000 lbs.
Travel Speed 7.5 – 10.9 MPH
Electrical  System 36 / 48V
Length to Forkface 98.8 – 113
Overhead Guard Height 90 – 93.3”
Overall Width 47.6 – 53.1″



Request a Quote

Don’t know exactly what you need? Not to worry. A member of our team will contact and assist you.

Model
Number
Load Capacity*
(lbs)
Max Travel Speed
Full Load (mph)
Max Lift Speed
Full Load (fpm)
Max Gradeability
Full Load (%)
Basic Right Angle
Stack** (in.)
7FBCU35 8,000 8.4 (36V), 10.9 (48V) 51.2 (36V), 72.9 (48 V) 16 (36V), 22 (48V) 102.6
7FBCU45 10,000 7.8 (36V), 10.9 (48V) 43 (36V), 57 (48V) 13 (36V), 18 (48V) 106.7
7FBCU55 12,000 7.5 (36V), 9.3 (48V) 37 (36V), 53 (48V) 14 (36V), 20 (48V) 116.9

* Based on 24″ Load center
** Add load length and clearance

Product specifications may not reflect the most current product details. All specifications should be verified by Shoppa’s Material Handling prior to purchase.

Performance  Icon Performance - Large Electric Forklift - Shoppa's Material Handling

  • AC drive system (MOSFET Transistor)
  • UL-approved model type “E”
  • Three forms of energy regeneration
    • Coast control
    • Plug braking
    • Foot braking
  • Load handling chopper
  • Digital multifunction display
  • Power select functions (S.P.H.)
  • 3-way hydraulic control valve

Ease of Service  Icon Service - Large Electric Forklift - Shoppa's Material Handling

  • AC drive motor (no brushes or commutator)
  • Easy access hydraulic motor
  • Easy access no-tools floorboard
  • Battery compartment hood assist dampers
  • Planned Maintenance Indicator
  • Easy Access Controller

Safety  Icon Safety - Large Electric Forklift - Shoppa's Material Handling

  • System of Active Stability™ (SAS)
    • Active control rear stabilizer
    • Active mast function controller
  • Operator Presence Sensing System (OPSS)
  • Key lowering interlock
  • Double-action parking brake
  • Bolt-on overhead guard
  • Electric horn

Ergonomics  Icon Ergonomics - Large Electric Forklift - Shoppa's Material Handling

  • Strategically configured instrument display
  • Hydrostatic Power Steering
  • Dual operator assist grips
  • Electric directional shift control
  • Memory tilt steering column
  • Two-spoke steering wheel
  • Cowl-mounted hydraulic controls
